Product Details
The precision alloy mainly applies to electrical component, hard glass, soft glass, glassy-closure alloy of ceramic match sealing, soft magnetic alloy, elastic alloy, including iron, nickel, cobalt alloy 4J29, iron-chromium alloy 4J28 , iron-nickel alloy 1J36, 1J50, 1J79, 1J80, 3J9, 4J42, 4J50 etc.. The product specifications include silk, belt, pipe, sheet and rod materials. The smelting process of the alloy is undertaken in the non-vacuum induction furnace and vacuum induction furnace, the other smelting methods which can meet the requirements also can be used.
Grade | Chemical composition % | Remarks | ||||||||||
C | P | S | Mn | Si | Cu | Cr | Mo | Ni | Co | Fe | ||
1J36 | ≤0.03 | ≤0.020 | ≤0.02 | ≤0.06 | ≤0.20 | / | 35.0/37.0 | The remaining amount | The chemical composition is allowed to deviate from the standard requirements when the alloy magnetic is in line with the standard. | |||
1J50 | ≤0.03 | ≤0.020 | ≤0.02 | 0.30/0.60 | 0.15/0.30 | ≤0.20 | / | / | 49.0/50.5 | / | The remaining amount | |
1J79 | ≤0.03 | ≤0.020 | ≤0.02 | 0.60/1.10 | 0.30/0.50 | ≤0.20 | 3.80/4.10 | 78.5/80.0 | The remaining amount | |||
1J80 | ≤0.03 | ≤0.020 | ≤0.02 | 0.60/1.10 | 1.10/1.50 | ≤0.20 | 2.60/3.00 | / | 79.0/81.5 | / | The remaining amount | |
3J9 | 0.02/0.26 | ≤0.030 | ≤0.02 | 1.80/2.20 | 1.3/1.70 | 19.0/20.5 | 1.60/1.85 | 9.0/10.5 | The remaining amount | |||
4J29 | ≤0.03 | ≤0.02 | ≤0.02 | ≤0.50 | ≤0.30 | ≤0.20 | ≤0.20 | ≤0.20 | 28.5/29.5 | 16.8/17.8 | The remaining amount | |
4J28 | ≤0.12 | ≤0.02 | ≤0.02 | ≤1.00 | ≤0.90 | 27.0/29.0 | ≤0.50 | The remaining amount | N≤0.02 | |||
4J42 | ≤0.05 | ≤0.02 | ≤0.02 | ≤0.80 | ≤0.30 | 41.5/42.5 | ≤1.0 | The remaining amount | Al≤0.10 | |||
4J50 | ≤0.05 | ≤0.02 | ≤0.02 | ≤0.80 | ≤0.30 | 49.5/50.5 | The remaining amount | Al≤0.10 | ||||
With wide experience and expertise, Beall Industry Group is one of the leading precision alloys manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price precision alloys for sale with us.
